Name: 3/4-16 JIC 37° Flare Female Swivel Branch Tee | GLS15T505-08-08
Brand: Green Line
SKU: GLS15T505-08-08
Price: 6.99 CAD
Availability: InStock

3/4-16 JIC 37° Flare Female Swivel Branch Tee | GLS15T505-08-08

Part #GLS15T505-08-08

$6.99

In general, tube fittings were first designed to allow connections between components using steel or copper tubing. In North America, the tubing was flared at the end and secured with a threaded nut and sometimes a back-up sleeve. Therefore, this type of fitting is most commonly referred to as a flare fitting, either according to JIC (Joint Industrial Council) which called for a 37° flare for steel tubing, or SAE (Society of Automotive Engineers) which specified a 45° flare on the softer copper tubing most commonly found in low pressure automotive applications. Today JIC fittings are widespread in hydraulic applications, while SAE adapters are commonly brass and are usually confined to truck and plumbing markets. Flare fittings are called by the size of tubing they connect to rather than the thread dimension. For example, a JIC in size -08 is designed to connect to 1/2" O.D. tubing, but the fitting actually measures 3/4" on the outside of the thread. JIC and SAE thread dimensions match exactly in sizes -02, -03, -04, -05, -08, and -10, and so will often serve quite well when interchanged in low pressure applications, since only the seat angle varies. However, in sizes -06, -12, and in larger sizes they will not interchange. Flare fittings can be readily identified by measuring the male thread dimension, the pitch (number of threads per inch), and the flare angle. Our Pulsar adapters are for general hydraulic use. Pressure ratings are dependent on size and thread design. Whenever possible, elbows and tees are forged one-piece designs rather than braised from components. However, where manufacturing quantities are insufficient to warrant forging, parts are braised.

Details

Brand	Green Line
Manufacturer Part Number	15T505-08-08
