Name: 6BTM with Built-in Boost Control | MSD6462
Brand: MSD
SKU: MSD6462
Price: 1075.99 CAD
Availability: InStock

6BTM with Built-in Boost Control | MSD6462

Part #MSD6462

$1,075.99

The 6 BTM is ideal for engines with a turbo or supercharger. Not only will the engine benefit from MSD's full power CD sparks, but there is also an adjustable boost/timing retard circuit to prevent detonation. When your turbo or blower forces the air/fuel mixture into the engine, the cylinder pressure inside the combustion chamber increases. The result is a great increase in power but this can also lead to detonation that can result in severe engine damage. The 6 BTM lets you dial away detonation by retarding the timing in relation to the boost pressure. A dash-mounted control knob lets you adjust the amount of timing retard. It can be adjusted from 0 degrees per pound of boost to 3 degrees per pound (up to 15 degrees). The 6 BTM also shares the Soft Touch Rev Control of the 6AL Ignition for overrev protection. The BTM is supplied with rubber shock mounts and rpm modules for 3,000, 6,000, 7,000, and 8,000 rpm.

Multiple spark, capacitive discharge ignition control
470 primary voltage output to coil
Accepts breaker points, amplifier and magnetic pickup trigger inputs
Works on 12 - 18 volt electrical system
Multiple sparks for 20° of crankshaft rotation
Retard the ignition timing 1 degrees-3 degrees per pound of boost, maximum of 15 degrees, with dash mounted adjustable control knob
CARB E.O. Approved
Supplied with 3,000, 6,000, 7,000 & 8,000 RPM Module
Supplied with rubber shock mounts
Programmable for 4, 6, or 8-cylinders by cutting red/blue wire loops
Built-in Soft Touch Rev Control is adjustable with RPM Modules
110 millijoules per spark up to 15,000 RPM

Rev Limiter

Details

Brand	MSD
Product Dimensions	7.37 x 24.38 x 27.43 inches
Manufacturer Part Number	6462
