Name: Cam/Cast Sleeve Assortment (9) | 57723180
Brand: Specialty Products
SKU: 57723180
Price: 191.31 CAD
Availability: OutOfStock

Cam/Cast Sleeve Assortment (9) | 57723180

Part #57723180

$191.31

These popular sleeves are widely used to adjust caster and/ or camber on many Ford and Mazda RWD & 4WD trucks. To install, simply loosen and remove upper ball joint pinch bolt. Remove top snap ring if one is present. Use 77880 or 88830 sleeve puller to remove the existing sleeve. To split camber and caster adjustment, rotate sleeve 45°. Save time during alignment, use 23199 zero degree sleeve to determine initial readings, then install correct sleeve. Note: Sleeves adjust to a smaller degree on Ford andMazda 4WD light trucks/SUVS. Set 23180 contains 1 each: 23181,23182,23183,23184,23185,23186,23187,23188,23199

Easily adjust caster and/or camber on many Ford and Mazda RWD & 4WD trucks
Use SPC 77880 or 88830 sleeve puller to remove the existing sleeve
Kit includes an assortment of 9 sleeves
Adjust camber and/or caster 0.25 to 3.5 degrees for RWD and 0.20 to 2.75 degrees for 4WD vehciles
